6-16 i3070 Series 5i Help
Troubleshooting
Top Pr es s A ssemb ly
Rear Safety Hook Detect Sensor PHS-16 015
Top Jig Lock SV5,1014 RS3,110
Top Jig Unlock SV6,1015 RS4,111
Top Jig Fully In Detect Sensor PHS-19 101
Front Safety Hook Detect Sensor PHS-17 100
Table 6- 4 Motors and Controls
Motor/Control ID
Presser Servo Motor M1
Zone 1 Motor M2
Zone 2 DC Motor M3, M4
Lighting LT1
Tester Self-test (not used) PB2 102, 1001
Bottom Jig Lock PB3 103, 1002
Drawer Control 1 PB4 104, 1003
Drawer Control 2 PB5 105, 1004
Top Jig Lock PB6 106, 1005
Maintenance Key Switch KS1 107
Emergency Stop EM2 015
Table 6- 3 Sensors
Sensor ID Signal to PLC
To Next Page
