Agilent Technologies Medalist i3070 5i Series User Manual

Test Development
i3070 Series 5i Help 3-11
Table 3- 2 ID Block: Pin Assignment
Pin 16 Pin 14 Pin 12 Pin 10 Pin 8 Pin 6 Pin 4 Pin 2
AF1
(Signal 404)
AF3
(Signal 406)
AF5
(Signal 408)
AF7
(Signal 410)
AF9
(Signal 412)
AF11(MSB)
(Signal 414)
Spare + (24V - T) board
orientation
Pin 15 Pin 13 Pin 11 Pin 9 Pin 7 Pin 5 Pin 3 Pin 1
AF0 (LSB)
(Signal 403)
AF2
(Signal 405)
AF4
(Signal 407)
AF6
(Signal 409)
AF8
(Signal 411)
AF10
(Signal 413)
Auto GND
(Signal “–”)
– (Com - T) board
orientation
Pin 16 Pin 14 Pin 12 Pin 10 Pin 8 Pin 6 Pin 4 Pin 2
Spare Spare Spare J1.10 J1.8 J1.6 J1.4 J1.2
Pin 15 Pin 13 Pin 11 Pin 9 Pin 7 Pin 5 Pin 3 Pin 1
Spare Spare Spare J1.9 J1.7 J1.5 J1.3 J1.1
Pin 16 Pin 14 Pin 12 Pin 10 Pin 8 Pin 6 Pin 4 Pin 2
Spare Spare LEM_M LEM_R LEM_A CET PWR USB VCC Data -
Pin 15 Pin 13 Pin 11 Pin 9 Pin 7 Pin 5 Pin 3 Pin 1
Spare Spare ASRU SW GND ASRU SW GND ASRU SW GND CET GND USB GND Data +
