Replacement Procedures
i3070 Series 5i Help 7-3
6 Use the hand crank to rotate the testhead. The direction depends on
the part being replaced.
Figure 7-1 Accessing the Testhead
Hand Crank
Handle
Guide Bar
Latch
Star Knob
Install hand crank
to rotate testhead
