Allen-Bradley MicroLogix 1200 - Page 49

Publication 1762-UM001D-EN-P - March 2004
Wiring Your Controller 3-13
Figure 3.10 1762-L24BXB and 1762-L24BXBR Sinking Input Wiring Diagram
Figure 3.11 1762-L24BXB and 1762-L24BXBR Sourcing Input Wiring Diagram
NOT
USED
IN 0 IN 2 IN 5 IN 7 IN 9
COM 1
IN 11 IN 13
COM 0
IN 1 IN 3 IN 4 IN 6 IN 8 IN 10 IN 12
-DCb
-DCa
+DCb
+DCb
+DCa
+DCa
NOT
USED
NOT
USED
0 IN 2 IN 5 IN 7 IN 9
COM1
IN 11 IN 13
COM0
IN 1 IN 3 IN 4 IN 6 IN 8 IN 10 IN 12
+DCb
+DCa
-DCb
-DCb
-DCa
-DCa
NOT
USED
