172 Rockwell Automation Publication 1766-UM001I-EN-P - June 2015
Appendix A Specifications
1762-IT4 Repeatability at 25 °C (77 °F)
(1) (2)
(1) Repeatability is the ability of the input module to register the same reading in successive measurements for the
same input signal.
(2) Repeatability at any other temperature in the 0...60 °C (32...140 °F) range is the same as long as the
temperature is stable.
Input Type Repeatability for 10
Hz Filter
Thermocouple J ±0.1 °C [±0.18 °F]
Thermocouple N (-110…1300 °C [-166…2372 °F]) ±0.1 °C [±0.18 °F]
Thermocouple N (-210…-110 °C [-346…-166 °F]) ±0.25 °C [±0.45 °F]
Thermocouple T (-170…400 °C [-274…752 °F]) ±0 .1 °C [±0.18 °F]
Thermocouple T (-270…-170 °C [-454…-274 °F]) ±1.5 °C [±2.7 °F]
Thermocouple K (-270…1370 °C [-454 °F…2498 °F]) ±0.1 °C [±0.18 °F]
Thermocouple K (-270…-170 °C [-454…-274 °F]) ±2.0 °C [±3.6 °F]
Thermocouple E (-220…1000 °C [-364…1832 °F]) ±0.1 °C [±0.18 °F]
Thermocouple E (-270…-220 °C [-454…-364 °F]) ±1.0 °C [±1.8 °F]
Thermocouples S and R ±0.4 °C [±0.72 °F]
Thermocouple C ±0.2 °C [±0.36 °F]
Thermocouple B ±0.7 °C [±1.26 °F]
±50 mV ±6 µV
±100 mV ±6 µV
1762-IT4 Accuracy
Input Type
(1)
With Autocalibration Enabled Without Autocalibration
Accuracy
(2) (3)
for 10 Hz, 50 Hz and 60 Hz
Filters (max.)
Maximum Temperature Drift
(2) (4)
at 25 °C [77 °F]
Ambient
at 0…60 °C
[32…140 °F]
Ambient
at 0…60 °C [32…140 °F]
Ambient
Thermocouple J (-210…1200 °C [-346…2192 °F]) ±0.6 °C [± 1.1 °F] ±0.9 °C [± 1.7 °F] ±0.0218 °C/ °C [±0.0218 °F/ °F]
Thermocouple N (-200…1300 °C [-328…2372 °F]) ±1 °C [± 1.8 °F] ±1.5 °C [±2.7 °F] ±0.0367 °C/ °C [±0.0367 °F/ °F]
Thermocouple N (-210…-200 °C [-346…-328 °F]) ±1.2 °C [±2.2 °F] ±1.8 °C [±3.3 °F] ±0.0424 °C/ °C [±0.0424 °F/ °F]
Thermocouple T (-230…400 °C [-382…752 °F]) ±1 °C [± 1.8 °F] ±1.5 °C [±2.7 °F] ±0.0349 °C/ °C [±0.0349 °F/ °F]
Thermocouple T (-270…-230 °C [-454…-382 °F]) ±5.4 °C [± 9.8 °F] ±7.0 °C [±12.6 °F] ±0.3500 °C/ °C [±0.3500 °F/ °F]
Thermocouple K (-230…1370 °C [-382…2498 °F]) ±1 °C [± 1.8 °F] ±1.5 °C [±2.7 °F] ±0.4995 °C/ °C [±0.4995 °F/ °F]
Thermocouple K (-270…-225 °C [-454…-373 °F]) ±7.5 °C [± 13.5 °F] ±10 °C [± 18 °F] ±0.0378 °C/ °C [±0.0378 °F/ °F]
Thermocouple E (-210…1000 °C [-346…1832 °F]) ±0.5 °C [± 0.9 °F] ±0.8 °C [±1.5 °F] ±0.0199 °C/ °C [±0.0199 °F/ °F]
Thermocouple E (-270…-210 °C [-454…-346 °F]) ±4.2 °C [± 7.6 °F] ±6.3 °C [±11.4 °F] ±0.2698 °C/ °C [±0.2698 °F/ °F]
Thermocouple R ±1.7 °C [± 3.1 °F] ±2.6 °C [± 4.7 °F] ±0.0613 °C/ °C [±0.0613 °F/ °F]
Thermocouple S ±1.7 °C [± 3.1 °F] ±2.6 °C [± 4.7 °F] ±0.0600 °C/ °C [±0.0600 °F/ °F]
Thermocouple C ±1.8 °C [±3.3 °F] ±3.5 °C [±6.3 °F] ±0.0899 °C/ °C [±0.0899 °F/ °F]
