Appendix F MicroLogix 1400 Distributed Network Protocol (DNP3)
This table shows RTC Accuracy. Configure the NEED_TIME IIN bit according
to this table, so that a DNP3 Master can send the time synchronization request
for more accurate times in the controller.
Download a User Program
via DNP3 Network
Using File-Control/Status of Requested Operation objects, a user program can
be downloaded/uploaded/initialized via DNP3 communication. Also, Serial
Channel 0 Status File, Ethernet Channel 1 Status File, and Serial Channel 2
Status File can be uploaded from the MicroLogix 1400.
All File-Control/Status of Requested Operation objects and supported
File-Control/Status of Requested Operation objects are listed in this section.
Unsolicited Response for File-Control/Status of Requested Operation objects is
not supported. All the responses are sent to DNP3 Master with Function Code
129(81h).
• g70v1 File-Control - File identifier : superseded, not supported
• g70v2 File-Control - Authentication : supported
• g70v3 File-Control - File command : supported
• g70v4 File-Control - File command status : supported
• g70v5 File-Control - File transport : supported
• g70v6 File-Control - File transport status : supported
• g70v7 File-Control - File descriptor : supported
• g70v8 File-Control - File specification string : not supported by Series A
controllers, supported by Series B controllers
• g91v1 Status of Requested Operation - Activate configuration : not
supported by Series A controllers, supported by Series B controllers
RTC Accuracy
Ambient Temperature RTC Accuracy
(1)
(1)
These numbers are maximum worst case values over a 31-day month.
0 °C (32 °F) -13...-121 seconds/month
25 °C (77 °F) 54...-5 seconds/month
40 °C (104 °F) 29...-78 seconds/month
55 °C (131 °F) -43...-150 seconds/month
