Allen-Bradley MicroLogix 1400 User Manual

Rockwell Automation Publication 1766-UM001I-EN-P - June 2015 7
Chapter 2
Install Your Controller
This chapter shows you how to install your controller. The only tools you require
are a flat or Phillips head screwdriver and drill. Topics include:
• agency certifications
• compliance to European Union Directives
• installation considerations
• safety considerations
• power considerations
• preventing excessive heat
• master control relay
• installing a memory module
• using the battery
• controller mounting dimensions
• controller and expansion I/O spacing
• mounting the controller
• mounting 1762 expansion I/O
• connecting 1762 expansion I/O
Agency Certifications
• UL Listed Industrial Control Equipment for use in Class I, Division 2,
Hazardous Locations, Groups A, B, C, D
• C-UL Listed Industrial Control Equipment for use in Canada
• CE compliant for all applicable directives
• RCM compliant for all applicable directives
• EAC compliant for all applicable directives
Compliance to European
Union Directives
This product has the CE mark and is approved for installation within the
European Union and EEA regions. It has been designed and tested to meet the
following directives.
EMC Directive
This product is tested to meet Council Directive 2004/108/EC Electromagnetic
Compatibility (EMC) and the following standards, in whole or in part,
documented in a technical construction file:

Allen-Bradley MicroLogix 1400 Specifications

General

Processor	32-bit
Expansion Modules	Up to 7 expansion I/O modules
Power Supply	24V DC or 120/240V AC
Programming Software	RSLogix 500
Communication Ports	Ethernet, RS-232/RS-485 combo port
Controller Type	Programmable Logic Controller (PLC)
Series	MicroLogix
Digital Outputs	12
Analog Inputs	6 (embedded)
Analog Outputs	2 (embedded)
High-Speed Counter	6 high-speed counters
Pulse Output	2 (embedded)
Ethernet Port	Yes
