264 Rockwell Automation Publication 1766-UM001I-EN-P - June 2015
Appendix F MicroLogix 1400 Distributed Network Protocol (DNP3)
• 32-bit Counter Threshold Config File Number (In Series B)
For Analog Input type data, you can configure Deadband information in the
Configuration file. Each element can be configured to the deadband value for
each point. An analog input event is generated if the absolute value of the
difference between the present value of an analog input point and the value that
was most recently queued as an event for that point exceeds the deadband value
that was configured in this file.
Related Configuration File Numbers:
• 16-bit Analog Input Deadband Config File Number (In Series B)
• 32-bit Analog Input Deadband Config File Number (In Series B)
• Short Floating Point Analog Input Deadband Config File Number (In
Series B)
For Analog Output type data, you can configure the object flag information in
the Configuration file. The upper byte of the configuration file of these objects is
used to configure the object flag. Other bits are reserved.
Related Configuration File Numbers:
• 16-bit Analog Input Deadband Config File Number (In Series B)
• 32-bit Analog Input Deadband Config File Number (In Series B)
• Short Floating Point Analog Input Deadband Config File Number (In
Series B)
Word Offet Description
Element 0 Threshold for point 0
Element 1 Threshold for point 1
Element 2 Threshold for point 2
Element 3 Threshold for point 3
Element 4 Threshold for point 4
Element 5 Threshold for point 5
…
Word Offet Description
Element 0 Deadband for point 0
Element 1 Deadband for point 1
Element 2 Deadband for point 2
Element 3 Deadband for point 3
Element 4 Deadband for point 4
Element 5 Deadband for point 5
…
