Rockwell Automation Publication 1766-UM001I-EN-P - June 2015 297
MicroLogix 1400 Distributed Network Protocol (DNP3) Appendix F
Object Flags for Binary Output
Bit Offset Name Description
0 ONLINE 0 when the controller is or was in Non-Executing mode.
1 when the controller is or was in Executing mode and the configuration file does not exist.
May be 1 when the controller is in Executing mode and the configuration file exists.
1 RESTART Always 0. Not used.
2 COMM_LOST Always 0. Not used.
3 REMOTE_FORCED Always 0. Not used.
4 LOCAL_FORCED Always 0. Not used.
5 reserved Always 0. Not used.
6 reserved Always 0. Not used.
7 STATE Reflects point state of Binary Output point.
Object Flags for Counter
Bit Offset Name Description
0 ONLINE 0 when the controller is or was in Non-Executing mode.
1 when the controller is or was in Executing mode and the configuration file does not
exist.
May be 1 when the controller is in Executing mode and the configuration file exists.
1 RESTART 0 when the controller is or was in Non-Executing mode.
0 when the controller is or was in Executing mode and the configuration file does not
exist.
May be 1 when the controller is in Executing mode and the configuration file exists.
2COMM_LOST
3 REMOTE_FORCED
4 LOCAL_FORCED
5 ROLLOVER
6DISCONTINUITY
7 reserved
Object Flags for Analog Input
Bit Offset Name Description
0 ONLINE 0 when the controller is or was in Non-Executing mode.
1 when the controller is or was in Executing mode and the configuration file does not
exist.
May be 1 when the controller is in Executing mode and the configuration file exists.
1 RESTART 0 when the controller is or was in Non-Executing mode.
0 when the controller is or was in Executing mode and the configuration file does not
exist.
May be 1 when the controller is in Executing mode and the configuration file exists.
2COMM_LOST
3 REMOTE_FORCED
4 LOCAL_FORCED
5 OVER_RANGE
6 REFERENCE_ERR
7 reserved
