Rockwell Automation Publication 1766-UM001I-EN-P - June 2015 321
MicroLogix 1400 Distributed Network Protocol (DNP3) Appendix F
17 CS0:17 CS2:17 Link Layer Error Codes
0: ERR_NO_ERROR
1: ERR_NO_RX_BUFFER
2: ERR_TOO_SHORT
3: ERR_TOO_LONG
4: ERR_UART_ERROR
5: ERR_BAD_CRC
6: ERR_CTS_TIMEOUT
7: ERR_CTS_DROP_MID_PKT
8: ERR_UNKNOWN_CHAR
18 CS0:18 CS2:18 Reserved - Always 0
19 CS0:19 CS2:19 Reserved - Always 0
20 CS0:20 CS2:20 Reserved - Always 0
21 CS0:21 CS2:21 Reserved - Always 0
22 CS0:22 CS2:22 Reserved - Always 0
23 CS0:23 CS2:23 Data Link Layer Active Node Table
24 CS0:24 CS2:24 Length
25 CS0:25 CS2:25 Format Code
26 CS0:26 CS2:26 Number of Nodes
27 CS0:27 CS2:27 Reserved - Always 0
28 CS0:28 CS2:28 Reserved - Always 0
29 CS0:29 CS2:29 Reserved - Always 0
30 CS0:30 CS2:30 Reserved - Always 0
31 CS0:31 CS2:31 Reserved - Always 0
32 CS0:32 CS2:32 Reserved - Always 0
33 CS0:33 CS2:33 Reserved - Always 0
34 CS0:34 CS2:34 Reserved - Always 0
35 CS0:35 CS2:35 Reserved - Always 0
36 CS0:36 CS2:36 Reserved - Always 0
37 CS0:37 CS2:37 Reserved - Always 0
38 CS0:38 CS2:38 Reserved - Always 0
39 CS0:39 CS2:39 Reserved - Always 0
40 CS0:40 CS2:40 Reserved - Always 0
41 CS0:41 CS2:41 Reserved - Always 0
42 CS0:42 CS2:42 Reserved - Always 0
43 CS0:43 CS2:43 List Category ID (10)
44 CS0:44 CS2:44 Length (14)
45 CS0:45 CS2:45 Format Code (2)
46 CS0:46 CS2:46 Pre-Send Time Delay
47 CS0:47 CS2:47 Node Address for this Slave
48 CS0:48 CS2:48 Reserved - always 0
Communication Status File Words
Words Offset File/Element
Description for
Channel 0
File/Element
Description for
Channel 2
Description
