Rockwell Automation Publication 1766-UM001I-EN-P - June 2015 323
MicroLogix 1400 Distributed Network Protocol (DNP3) Appendix F
68 CS0:68 CS2:68 Transport Function Layer Error Codes
0: NO_ERROR - No error found in the Transport Layer.
1: DISCARD_NOT_FIRST_SEG - The received packet was discarded since it was
not a first segment.
2: DISCARD_DUPLICATED_AND_MORE_SEG - The received packet was discarded
since it had the same sequence number as previous, more segments are expected.
3: DISCARD_DUPLICATED_AND_FINAL_SEG - The received packet was discarded
since it had the same sequence number as previous, final segment received.
4: DISCARD_OUT_OF_ORDER_SEG - The received packet was discarded since the
sequence number was out of order.
69 CS0:69 CS2:69 Transport Layer Error Count
70 CS0:70 CS2:70 End Of List Category ID (0)
Communication Status File Words
Words Offset File/Element
Description for
Channel 0
File/Element
Description for
Channel 2
Description
