Allen-Bradley MicroLogix 1400 User Manual

336 Rockwell Automation Publication 1766-UM001I-EN-P - June 2015
Appendix F MicroLogix 1400 Distributed Network Protocol (DNP3)
Request 21 (0x15) FC_DISABLE_UNSOLICITED Yes MicroLogix 1400 parses
Request 22 (0x16) FC_ASSIGN_CLASS No
Request 23 (0x17) FC_DELAY_MEASURE Yes MicroLogix 1400 parses. Used for non-LAN
Request 24 (0x18) FC_RECORD_CURRENT_TIME No Used for LAN
Request 25 (0x19) FC_OPEN_FILE Yes MicroLogix 1400 parses
Request 26 (0x1A) FC_CLOSE_FILE Yes MicroLogix 1400 parses
Request 27 (0x1B) FC_DELETE_FILE Yes MicroLogix 1400 parses
Request 28 (0x1C) FC_GET_FILE_INFO No
Request 29 (0x1D) FC_AUTHENTICATE_FILE Yes MicroLogix 1400 parses
Request 30 (0x1E) FC_ABORT_FILE No
Request 31 (0x1F) FC_ACTIVATE_CONFIG No
Request 32 (0x20) FC_AUTHENTICATE_REQ No
Request 33 (0x21) FC_AUTHENTICATE_ERR No
34 (0x22) to
128 (0x80)
No Reserved.
Response 129 (0x81) FC_RESPONSE Yes MicroLogix 1400 sends
Response 130 (0x82) FC_UNSOLICITED_RESPONSE Yes MicroLogix 1400 sends
Response 131 (0x83) FC_AUTHENTICATE_RESP No
132 (0x84) to
255 (0xFF)
No Reserved.
Function Codes for MicroLogix 1400 Series B Controllers
Message
Type
Function
Code
Name MicroLogix
1400 Support
Description
Confirmation 0 (0x00) FC_CONFIRM Yes MicroLogix 1400 parses/sends
Request 1 (0x01) FC_READ Yes MicroLogix 1400 parses
Request 2 (0x02) FC_WRITE Yes MicroLogix 1400 parses
Request 3 (0x03) FC_SELECT Yes MicroLogix 1400 parses
Request 4 (0x04) FC_OPERATE Yes MicroLogix 1400 parses
Request 5 (0x05) FC_DIRECT_OPERATE Yes MicroLogix 1400 parses
Request 6 (0x06) FC_DIRECT_OPERATE_NR Yes MicroLogix 1400 parses
Request 7 (0x07) FC_IMMED_FREEZE Yes MicroLogix 1400 parses
Request 8 (0x08) FC_IMMED_FREEZE_NR Yes MicroLogix 1400 parses
Request 9 (0x09) FC_FREEZE_CLEAR Yes MicroLogix 1400 parses
Request 10 (0x0A) FC_FREEZE_CLEAR_NR Yes MicroLogix 1400 parses
Request 11 (0x0B) FC_FREEZE_AT_TIME No
Request 12 (0x0C) FC_FREEZE_AT_TIME_NR No
Request 13 (0x0D) FC_COLD_RESTART Yes MicroLogix 1400 parses. MicroLogix 1400 should not be in the
executing mode and any program and files should not be in
open state.
Function Codes for MicroLogix 1400 Series A Controllers
Message
Type
Function
Code
Name MicroLogix
1400 Support
Description
