362 Rockwell Automation Publication 1766-UM001I-EN-P - June 2015
Appendix G Connecting to Networks via Ethernet Interface
The newest version of the utility can be downloaded from
http://www.ab.com/networks/ethernet/bootp.html
. The device must have
BOOTP enabled (factory default) or DHCP enabled to use the utility.
To configure your device using the BOOTP utility, perform the following steps.
1. Run the BOOTP/DHCP server utility software. It will ask you to
configure your network settings before using the BOOTP/DHCP server
tool. Enter your Ethernet settings for Subnet Mask and Gateway. If you are
not sure about it, get a help from your system administrator. Just leave
Primary DNS, Secondary DNS, and Domain Name (If corresponding
information is allocated to the PC where BOOTP/DHCP server utility is
installed, enter the same information.)
2. In the Request History panel you will see the hardware addresses of
devices issuing BOOTP or DHCP requests.
