372 Rockwell Automation Publication 1766-UM001I-EN-P - June 2015
Appendix H System Loading and Heat Dissipation
1762-OB8 1.6 W x number of modules 1.6 W x _________ W
1762-OB16 2.9 W x number of modules 2.9 W x _________ W
1762-OB32T 3.4 W x number of modules 3.4 W x _________ W
1762-OF4 3.8 W x number of modules 3.8 W x _________ W
1762-OV32T 2.7 W x number of modules 2.7 W x _________ W
1762-OW8 2.9 W x number of modules 2.9 W x _________ W
1762-OW16 6.1 W
(1)
x number of modules 6.1 W
(1)
x _________ W
1762-OX6I 2.8 W x number of modules 2.8 W x _________ W
1762-IQ8OW6 4.4 W x number of modules 4.4 W x _________ W
Add Sub-Totals to determine Heat Dissipation W
(1) Only applicable to Series B I/O modules.
Heat Dissipation
