Using High-Speed Outputs 145
PTOX Output (OUT)
The PTOX OUT (Output) variable defines the output (O0:0/2, O0:0/3 or
or O0:0/4) that the PTO instruction controls. This variable is set within the
function file folder when the control program is written and cannot be set
by the user program.
• When OUT = 2, PTO pulses output 2 (O0:0.0/2) of the embedded
outputs.
• When OUT = 3, PTO pulses output 3 (O0:0.0/3) of the embedded
outputs
• When OUT = 4, PTO pulses output 4 (O0:0.0/4) of the embedded
outputs.
IS - Idle Status PTOX:0/IS bit 0 or 1 status read only 148
ED - Error Detected Status PTOX:0/ED bit 0 or 1 status read only 148
NS - Normal Operation Status PTOX:0/NS bit 0 or 1 status read only 149
JPS - Jog Pulse Status PTOX:0/JPS bit 0 or 1 status read only 155
JCS - Jog Continuous Status PTOX:0/JCS bit 0 or 1 status read only 156
ADI - Accel/Decel Pulses Independent PTOX:0/ADI bit 0 or 1 control read/write 151
JP - Jog Pulse PTOX:0/JP bit 0 or 1 control read/write 155
JC - Jog Continuous PTOX:0/JC bit 0 or 1 control read/write 156
EH - Enable Hard Stop PTOX:0/EH bit 0 or 1 control read/write 149
EN - Enable Status (follows rung state) PTOX:0/EN bit 0 or 1 status read only 149
ER - Error Code PTOX:0.ER word (INT) -2…7 status read only 157
OF - Output Frequency (Hz) PTOX:0.OF long word
(32-bit INT)
0…100,000 control read/write 150
OFS - Operating Frequency Status (Hz) PTOX:0.OFS long word
(32-bit INT)
0…100,000 status read only 150
JF - Jog Frequency (Hz) PTOX:0.JF long word
(32-bit INT)
0…100,000 control read/write 155
TOP - Total Output Pulses
To Be Generated
PTOX:0.TOP long word
(32-bit INT)
0…2,147,483,647 control read/write 151
OPP - Output Pulses Produced PTOX:0.OPP long word
(32-bit INT)
0…2,147,483,647 status read only 151
ADP - Accel/Decel Pulses PTOX:0.ADP long word
(32-bit INT)
see p. 152 control read/write 152
Pulse Train Output Function File (PTOX:0)
Sub-Element Description Address Data Format Range Type User Program
Access
For More
Information
Sub-Element
Description
Address Data Format Range Type User Program
Access
OUT - Output PTOX:0.OU
T
word (INT) 2…4 control read only
