174 Relay-Type (Bit) Instructions
Addressing Modes and File Types can be used as shown in the following
table:
OSF Storage and Output Bits Operation
Rung State Transition Storage Bit Output Bit
true-to-false (one scan) bit is reset bit is set
false-to-false bit is reset bit is reset
false-to-true and true-to-true bit is set bit is reset
OSR and OSF Instructions Valid Addressing Modes and File Types
For definitions of the terms used in this table see Using the Instruction Descriptions on page 92.
Parameter
Data Files Function Files
CS - Comms IOS - I/O DLS - Data Log
Address
Mode
Address Level
O I S B T, C, R N F ST L MG, PD RI/RIX PLS RTC HSC PTOX, PWMX STI EII BHI MMI LCD Immediate Direct Indirect Bit Word Long Word Element
Storage Bit • • • •
Output Bit • • • • • •
• •
