Publication 1766-RM001A-EN-P - October 2008
Math Instructions 203
Addressing Floating Point Files
The addressing format for floating point data files is shown below.
Programming Floating Point Values
The following table shows items to consider when using floating point
data.
Table 2:
Format Explanation
Ff:e F Floating Point file
f File number The valid file number range is from 8 (default) to 255.
: Element delimiter
e Element number The valid element number range is from 0…255.
Examples: F8:2
F10:36
Floating Point File 8, Element 2
Floating Point File 10, Element 36
IMPORTANT
These rules do not apply to the SCP instruction. See page 210 for the rules for
that instruction.
