Publication 1766-RM001A-EN-P - October 2008

296 Sequencer Instructions

(1) See Important note about indirect addressing.

(2) File Direct and File Indirect addressing also applies.

(3) Control file only.

IMPORTANT

You cannot use indirect addressing with: S, MG, PD, RTC, HSC, PTOX,

PWMX, STI, EII, BHI, MMI, CS, IOS, LCD, and DLS files.
