Allen-Bradley MicroLogix 1400 User Manual

Publication 1766-RM001A-EN-P - October 2008
Socket Interface Using CIP Generic Messaging 483
each Write does not require an application response or
acknowledgement. The application protocol determines the exact
sequence of application transactions.
Typical Sequence of Transactions For UDP With OpenConnection
The following diagram shows a typical sequence of socket interface
transactions for UDP communications when using the OpenConnection
service to specify the destination address.
The exact sequence of sending and receiving data depends on the
application protocol.
Typical Sequence of Transactions for UDP Without OpenConnection
MSG in Ladder
Program
Ethernet Subsystem
10.10.10.10
Remote Ethernet Device
10.10.10.11
CreateSocket
Port=49100
CreateSocket Response
Instance=102
Write
10.10.10.11?Port=49200
Data = abc
Data = abc Receive Data From
Port = 49200
Write Response
The response is returned to the
controller as soon as the data is sent
Read
Timeout = 10000 ms
Send Data To
10.10.10.10?port=49100
Data = xyz
Read Response
10.10.10.11?Port=49200
Data = xyz
Typical Sequence of Transactions for UDP With OpenConnection
MSG in Ladder
Program
Ethernet Subsystem
10.10.10.10
Remote Ethernet Device
10.10.10.11
CreateSocket
Port=49100
CreateSocket Response
Instance=102
OpenConnection
10.10.10.11?Port=49200
OpenConnection Response
