Allen-Bradley MicroLogix 1400 User Manual

Publication 1766-RM001A-EN-P - October 2008
Protocol Configuration 617
Modbus Slave Memory Map
The modbus Memory map is summarized in and detailed in :
Modbus to MicroLogix Memory Map - Summary
Modbus
Addressing
Description Valid MicroLogix Addressing
File Type Data File Number Address
0001…4096 Read/Write Modbus Coil Data space Bit (B) or Integer (N) 3…255 bits 0…4095
10001…14096 Read-Only Modbus Contact Data space Bit (B) or Integer (N) 3…255 bits 0…4095
30001…30256 Read-Only Modbus Input Register space Bit (B) or Integer (N) 3…255 words 0…255
30501…30532 Modbus Communication Parameters Communication Status File - -
31501…31566 Read-Only System Status File space Status (S) 2 words 0…65
40001…40256 Read/Write Modbus Holding Register space Bit (B) or Integer (N) 3…255 words 0…255
40257…41280
(1)
Read/Write Modbus Holding Register space Bit (B) or Integer (N) 3…255 words 0…255
of four Holding
Register files
41501…41566 Read/Write System Status File space Status (S) 2 words 0…65
41793…42048
(1)
Read/Write Modbus Holding Register space Bit (B) or Integer (N) 3…255 words 0…255
of the last
Holding
Register file
(1) These addresses only become active when specially configured for expanded holding registers.
