Allen-Bradley MicroLogix 1400 User Manual

Publication 1766-RM001A-EN-P - October 2008
Function Files 73
13 - Link Layer Error Count
14 - Link Layer Error Code
15…22 - Reserved
Modbus RTU Master Diagnostic Counters Block (Presentation Layer)
Word Bit Description
52 - Diagnostic Counters Category Identifier Code (always 6)
53 - Length (always 32)
54 - Format Code (always 0)
55 - ERR 1: Illegal Function
56 - Last Device Reporting ERR 1
57 - ERR 2: Illegal Data Address
58 - Last Device Reporting ERR 2
59 - ERR 3: Illegal Data Value
60 - Last Device Reporting ERR 3
61 - ERR 4: Slave Device Failure
62 - ERR 5: Acknowledge
63 - ERR 6: Slave Device Busy
64 - ERR 7: Negative Acknowledgement
65 - ERR 8: Memory Parity Error
66 - Non-Standard Response
67 - Last Device Reporting ERR 4 to ERR 8 or Non-Standard Response
68 and 69 - Reserved (always 0)
Modbus RTU Master Diagnostic Counters Block (Data Link Layer)
Word Bit Description
efesotomasyon.com - Allen Bradley,Rockwell,plc,servo,drive

Allen-Bradley MicroLogix 1400 Specifications

General

Processor	32-bit
Expansion Modules	Up to 7 expansion I/O modules
Power Supply	24V DC or 120/240V AC
Programming Software	RSLogix 500
Communication Ports	Ethernet, RS-232/RS-485 combo port
Controller Type	Programmable Logic Controller (PLC)
Series	MicroLogix
Digital Outputs	12
Analog Inputs	6 (embedded)
Analog Outputs	2 (embedded)
High-Speed Counter	6 high-speed counters
Pulse Output	2 (embedded)
Ethernet Port	Yes
