Allen-Bradley MicroLogix 1400

To Next Page

To Previous Page

Publication 1766-RM001A-EN-P - October 2008

Function Files 75

ASCII Diagnostic Counters Block

Word Bit Description

6 - DLL Diagnostic Counters Category Identifier code (always 2)

7 - Length (always 30)

8 - Format Code (always 5)

90CTS

1RTS

2 Reserved

3 Reserved

4…15 Reserved

10 0 Software Handshaking Status

1…15 Reserved

11 - Echo Character Count

12 - Received Character Count

13…18 - Reserved

19 - Bad Character Count

20…22 - Reserved
