Allen-Bradley MicroLogix 1400 User Manual

Publication 1766-RM001A-EN-P - October 2008
76 Function Files
DNP3 Slave Diagnostic Counters Block (Data Link Layer)
Word Bit
Access
Description
RLL
Exe
c
Non-Exe
c
6 - RO RO RO DLL Diagnostic Counters Category Identifier code
(2)
7 - RO RO RO Length: 30 (15 words to follow including format
code)
8 - RO RO RO Counters Format Code: 11 - DNP3 Slave
9 15…4 RO RO RO Reserved Modem Control Line States - Always
zero
3 Channel 0 - DCD
Channel 2 - DCD
2 Reserved Modem Control Line States - Always
zero
1RTS
0CTS
10 0 RO RO RO Total Message Packets Sent
11 - RO RO RO Total Message Packets Received for this node
12 - RO RO RO Total Packets Observed
13 - RO RO RO Undelivered Message Packets
14 - RO RO RO Message Packets Retried
15 - RO RO RO NAK Packets Received
16 - RO RO RO Link Layer Error Count
17 - RO RO RO Link Layer Error Code
18 - RO RO RO Reserved - Always zero
19 - RO RO RO Reserved - Always zero
20 - RO RO RO Reserved - Always zero
21 - RO RO RO Reserved - Always zero
22 - RO RO RO Reserved - Always zero
