Allen-Bradley MicroLogix 1400 - InputOutput Status File

To Next Page

To Previous Page

Publication 1766-RM001A-EN-P - October 2008

Function Files 87

161

162

Low word Total Replies Received

High word

163

164

Low word Total Replies Sent with Error

High word

165

166

Low word Total Replies Received with Error

High word

167

168

Low word Total Replies Timed Out

High word

Ethernet Diagnostic Counters Block (continued)

Word Bit Description
