Allen-Bradley PanelView Plus 7 Migration Guide

Rockwell Automation Publication 2711P-AP006C-EN-P - November 2018 21
Select a Terminal Replacement Chapter 2
550
2711-B5A15
167
(6.57)
266
(10.47)
256 x 128
ControlNet
2711P-T6C21D8S
123
(4.84)
156
(6.14)
640 x 480
One
Ethernet
port
N/A
PanelView Plus 7 Standard 6 in.
terminal benefits:
Higher resolution
Application limits:
• Max. screen count: 25
• Max. alarm messages: 200
• Max. number of controllers: 1
Communication = Ethernet
(dual Ethernet ports are
available).
Operator input = only touch.
Power input = only DC.
Conformal coat = No.
2711-B5A15L1
2711-B5A2
DH-485
2711-B5A2L1
2711-B5A3
2711-B5A3L1
2711-B5A5
RS-232
(DH-485)
2711-B5A5L1
2711-B5A9
2711-B5A9L1
2711-B5A8
DH+
2711-B5A8L1
2711-B5A20
EtherNet/IP
2711-B5A20L1
2711-T5A1L1
152
(6.0)
185
(7.28)
256 x 128
Remote I/O
2711-T5A10L1
DeviceNet
2711-T5A14L1
2711-T5A12L1 RS-232
2711-T5A16L1
RS-232
(DF1)
2711-T5A15L1 ControlNet
2711-T5A2L1
DH-485
2711-T5A3L1
2711-T5A5L1
RS-232
(DH-485)
2711-T5A9L1
2711-T5A8L1 DH+
2711-T5A20L1 EtherNet/IP
PanelView Standard 550 Terminals Primary Replacement Options (continued)
PanelView Standard Terminals PanelView Plus 7 Terminals – Primary Replacement Options
Panel Cutout
Dimensions
Panel Cutout
Dimensions
Model Cat. No.
Height mm (in.) Width mm (in.)
Display
Resolution
Comm. Cat. No.
Height mm (in.) Width mm (in.)
Display
Resolution
Comm.
Adapter
Kit Cat.
No.
Notes

Allen-Bradley PanelView Plus 7 Specifications

General

Operating System	Windows CE 6.0
Memory	512 MB RAM
Mounting	Panel mount
Display Type	Color TFT LCD
Processor	ARM Cortex-A8
Storage	512 MB Flash
Communication Ports	Ethernet, USB, Serial
Input Voltage	24V DC
Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Rating	NEMA 4X
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Relative Humidity	5% to 95% non-condensing
Certifications	CE, UL, cUL
Display Sizes	4.3", 7", 10", 15", 19"
Touchscreen	Resistive or Projected Capacitive (depending on model)
