Allen-Bradley PanelView Plus 7 Migration Guide

Rockwell Automation Publication 2711P-AP006C-EN-P - November 2018 63
Review Object Mapping Chapter 5
Reviewing Mapping of
Communication Networks
This table shows communication protocols that are supported by
PanelBuilder32 and FactoryTalk View ME applications.
Table 12 - Mapping of Communication Networks
PanelBuilder32
Communication Protocols
FactoryTalk View ME Communication
Protocols
RS-232 (DF1) RS-232 (DF1)
RS-232 (DH-485) RS-232 (DH-485)
DH-485 DH-485
DH+™ DH+
Does not support nodes that use the
AutoMax® node type
EtherNet/IP
– EtherNet/IP controller address
– EtherNet/IP CIP
– Assembly object
EtherNet/IP
– Supported
–Not supported
–Not supported
RIO RIO
(1)
(1) Remote I/O and DeviceNet communication modules are not available for
PanelView Plus 6 terminals.
DeviceNet Not supported
(1)
ControlNet ControlNet
KEPWare communication drivers for third-
party controllers

Allen-Bradley PanelView Plus 7 Specifications

General

Operating System	Windows CE 6.0
Memory	512 MB RAM
Mounting	Panel mount
Display Type	Color TFT LCD
Processor	ARM Cortex-A8
Storage	512 MB Flash
Communication Ports	Ethernet, USB, Serial
Input Voltage	24V DC
Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Rating	NEMA 4X
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Relative Humidity	5% to 95% non-condensing
Certifications	CE, UL, cUL
Display Sizes	4.3", 7", 10", 15", 19"
Touchscreen	Resistive or Projected Capacitive (depending on model)
