Allen-Bradley PanelView Plus 7 Migration Guide

28 Rockwell Automation Publication 2711P-AP006C-EN-P - November 2018
Chapter 2 Select a Terminal Replacement
PanelView Standard 900 Terminals Conversions
See the tables in this section for primary and secondary conversions for
PanelView Standard 900 terminals.
PanelView Standard 900 Terminals Primary Replacement Options
PanelView Standard Terminals PanelView Plus 7 Terminals – Primary Replacement Options
Panel Cutout
Dimensions
Panel Cutout
Dimensions
Model Cat. No.
Height mm (in.) Width mm (in.)
Display
Resolution
Comm. Cat. No.
Height mm (in.) Width mm (in.)
Display
Resolution
Comm.
Adapter
Kit Cat.
No.
Notes
900
2711-K9A1
249
(9.8)
406
(15.97)
640 x 400
Remote I/O
2711P-B10C22A9P
224
(8.82)
335
(13.19)
800 x 600
Dual
Ethernet
ports
2711P-
RAAK10
PanelView Plus 7 Performance
10.4 in. terminal benefits:
•Higher resolution
•DLR
Communication = Ethernet.
Operator input = keypad and
touch.
Power input = AC or DC.
Conformal coat = No.
Adapter kit is necessary for
drop-in replacement.
2711-K9A1L1 2711P-B10C22D9P
2711-K9A10
DeviceNet
2711P-B10C22A9P
2711-K9A10L1 2711P-B10C22D9P
2711-K9A14L1 2711P-B10C22D9P
2711-K9A12
RS-232
2711P-B10C22A9P
2711-K9A12L1 2711P-B10C22D9P
2711-K9A5 2711P-B10C22A9P
2711-K9A5L1 2711P-B10C22D9P
2711-K9A9 2711P-B10C22A9P
2711-K9A9L1 2711P-B10C22D9P
2711-K9A15
ControlNet
2711P-B10C22A9P
2711-K9A15L1 2711P-B10C22D9P
2711-K9A2
DH-485
2711P-B10C22A9P
2711-K9A2L1 2711P-B10C22D9P
2711-K9A3 2711P-B10C22A9P
2711-K9A3L1 2711P-B10C22D9P
2711-K9A8
DH+
2711P-B10C22A9P
2711-K9A8L1 2711P-B10C22D9P
2711-K9C1
640 x 480
Remote I/O
2711P-B10C22A9P
2711-K9C1L1 2711P-B10C22D9P
2711-K9C10
DeviceNet
2711P-B10C22A9P
2711-K9C10L1 2711P-B10C22D9P
2711-K9C14 2711P-B10C22A9P
2711-K9C14L1 2711P-B10C22D9P
2711-K9C12
RS-232
2711P-B10C22A9P
2711-K9C12L1 2711P-B10C22D9P
2711-K9C9 2711P-B10C22A9P
2711-K9C9L1 2711P-B10C22D9P
2711-K9C16
RS-232
(DF1)
2711P-B10C22A9P
2711-K9C16L1 2711P-B10C22D9P
2711-K9C15
ControlNet
2711P-B10C22A9P
2711-K9C15L1 2711P-B10C22D9P
2711-K9C3 DH-485 2711P-B10C22A9P

Allen-Bradley PanelView Plus 7 Specifications

General

Operating System	Windows CE 6.0
Memory	512 MB RAM
Mounting	Panel mount
Display Type	Color TFT LCD
Processor	ARM Cortex-A8
Storage	512 MB Flash
Communication Ports	Ethernet, USB, Serial
Input Voltage	24V DC
Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Rating	NEMA 4X
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Relative Humidity	5% to 95% non-condensing
Certifications	CE, UL, cUL
Display Sizes	4.3", 7", 10", 15", 19"
Touchscreen	Resistive or Projected Capacitive (depending on model)
