Select a Terminal Replacement Chapter 2
600
2711-B6C15
192
(7.55)
290
(11.40)
320 x 234
ControlNet
2711P-T7C21D8S
142
(5.59)
184
(7.24)
640 x 480
One
Ethernet
port
N/A
PanelView Plus 7 Standard 6.5 in.
terminal benefits:
Higher resolution
Application limits:
• Max. screen count: 25
• Max. alarm messages: 200
• Max. number of controllers: 1
Communication = Ethernet (dual
Ethernet ports are available).
Operator input = only touch.
Power input = only DC.
Conformal coat = No.
2711-B6C15L1
2711-B6C2
DH-485
2711-B6C2L1
2711-B6C3
2711-B6C3L1
2711-B6C5
RS-232
(DH-485)
2711-B6C5L1
2711-B6C9
2711-B6C9L1
2711-B6C8
DH+
2711-B6C8L1
2711-B6C20
EtherNet/IP
2711-B6C20L1
2711-T6C1L1
152
(6.0)
185
(7.28)
320 x 234
Remote I/O
2711P-T7C22D9P
142
(5.59)
184
(7.24)
640 x 480
Dual
Ethernet
ports
N/A
PanelView Plus 7 Performance
6.5 in. terminal benefits:
•Higher resolution
•DLR
Communication = Ethernet.
Operator input = keypad and
touch.
Power input = AC or DC.
Conformal coat = Yes
(1)
Adapter kit is necessary for drop-
in replacement.
2711-T6C10L1
DeviceNet
2711-T6C14L1
2711-T6C12L1 RS-232
2711-T6C16L1
RS-232
(DF1)
2711-T6C15L1 ControlNet
2711-T6C2L1
DH-485
2711-T6C3L1
2711-T6C5L1
RS-232
(DH-485)
2711-T6C9L1
2711-T6C8L1 DH+
2711-T6C20L1 EtherNet/IP
(1) Conformal coating is available for all DC-power, touch terminals. To order a terminal that is conformal-coated, add K to the end of a DC-power, touch catalog number; for example, 2711P-T7C22D9PK.
PanelView Standard 600 Terminals Secondary Replacement Options (continued)
PanelView Standard Terminals PanelView Plus 7 Terminals – Secondary Replacement Options
Panel Cutout
Dimensions
Panel Cutout
Dimensions
Model Cat. No.
Height
mm (in.)
Width
mm (in.)
Display
Resolution
Comm. Cat. No.
Height
mm (in.)
Width
mm (in.)
Display
Resolution
Comm.
Adapter
Kit Cat.
No.
Notes
