Allen-Bradley PanelView Plus 7 Migration Guide

44 Rockwell Automation Publication 2711P-AP006C-EN-P - November 2018
Chapter 2 Select a Terminal Replacement
Adapter Kit Conversion Table
The adapter kit provides hardware for installing a PanelView Plus 7
Performance terminal into the cutout of the existing PanelView terminal. See
the Adapter Kit for PanelView 5500 and PanelView Plus 7 Performance
Te r m i n a l s , p u b l i c a ti o n VIEW-IN0002
.
IMPORTANT These adapter kits are for PanelView Plus 7 Performance terminals.
Do not install a PanelView Plus 7 Standard terminal with these adapter kits. The bezel of the standard terminal can be
damaged, which can reduce the effectiveness of the seal and damage the terminal and components that are installed in the
cabinet.
Adapter Kit Cat. No.
Replace this Existing PanelView Standard or PanelView
Enhanced Terminal…
With this PanelView Plus 7 Performance Terminal
2711P-RAAT7 N/A 6.5 in. touch screen
2711P-RAAK7 600 terminal, keypad, or keypad with touch screen 6.5 in. keypad with touch screen
2711P-RAAT10 900 terminal, touch screen 10.4 in. touch screen
2711P-RAAK10 900 terminal, keypad 10.4 in. keypad with touch screen
2711P-RAAT12 1000 and 1000e terminals, touch screen 12.1 in. touch screen
2711P-RAAT12K 1000 and 1000e terminals, keypad 12.1 in. touch screen
2711P-RAAT15 1400 and 1400e terminals, touch screen 15 in. touch screen
2711P-RAAK15 1400 and 1400e terminals, keypad 15 in. keypad with touch screen

Allen-Bradley PanelView Plus 7 Specifications

General

Operating System	Windows CE 6.0
Memory	512 MB RAM
Mounting	Panel mount
Display Type	Color TFT LCD
Processor	ARM Cortex-A8
Storage	512 MB Flash
Communication Ports	Ethernet, USB, Serial
Input Voltage	24V DC
Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Rating	NEMA 4X
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Relative Humidity	5% to 95% non-condensing
Certifications	CE, UL, cUL
Display Sizes	4.3", 7", 10", 15", 19"
Touchscreen	Resistive or Projected Capacitive (depending on model)
