20 Rockwell Automation Publication 2711P-AP006C-EN-P - November 2018
Chapter 2 Select a Terminal Replacement
PanelView Standard 550 Terminals Conversions
See the tables in this section for primary and secondary conversions for
PanelView Standard 550 terminals.
PanelView Standard 550 Terminals Primary Replacement Options
PanelView Standard Terminals PanelView Plus 7 Terminals – Primary Replacement Options
Panel Cutout
Dimensions
Panel Cutout
Dimensions
Model Cat. No.
Height
mm (in.)
Width
mm (in.)
Display
Resolution
Comm. Cat. No.
Height
mm (in.)
Width
mm (in.)
Display
Resolution
Comm.
Adapter
Kit Cat.
No.
Notes
550
2711-K5A1
167
(6.57)
266
(10.47)
256 x 128
Remote I/O
2711P-T6C21D8S
123
(4.84)
156
(6.14)
640 x 480
One
Ethernet
port
N/A
PanelView Plus 7 Standard 6 in.
terminal benefits:
Higher resolution
Application limits:
• Max. screen count: 25
• Max. alarm messages: 200
• Max. number of controllers: 1
Communication = Ethernet
(dual Ethernet ports are
available).
Operator input = only touch.
Power input = only DC.
Conformal coat = No.
2711-K5A1L1
2711-K5A10
DeviceNet
2711-K5A10L1
2711-K5A14
2711-K5A14L1
2711-K5A12
RS-232
2711-K5A12L1
2711-K5A16
RS-232
(DF1)
2711-K5A16L1
2711-K5A15
ControlNet
2711-K5A15L1
2711-K5A2
DH-485
2711-K5A2L1
2711-K5A3
2711-K5A3L1
2711-K5A5
RS-232
(DH-485)
2711-K5A5L1
2711-K5A9
2711-K5A9L1
2711-K5A8
DH+™
2711-K5A8L1
2711-K5A20
EtherNet/IP
2711-K5A20L1
2711-B5A1
Remote I/O
2711-B5A1L1
2711-B5A10
DeviceNet
2711-B5A10L1
2711-B5A14
2711-B5A14L1
2711-B5A12
RS-232
2711-B5A12L1
2711-B5A16
RS-232
(DF1)
2711-B5A16L1
To Next Page
