Allen-Bradley PanelView Plus 7 Migration Guide

Rockwell Automation Publication 2711P-AP006C-EN-P - November 2018 61
Chapter 5
Review Object Mapping
Introduction
In this chapter, you review how objects and alarms from PanelBuilder®32
software map to FactoryTalk® View Machine Edition (ME) software.
Before You Begin
• Review migration considerations (Chapter 1).
• Select a PanelView™ Plus 7 terminal replacement and adapter kit, if
necessary (Chapter 2).
• Optionally install the PanelView Plus 7 terminal in the existing
PanelView Standard panel cutout (Chapter 2).
• Import your PanelBuilder32 .pba application into FactoryTalk View ME
software (Chapter 3).
• Review the conversion log for your imported application (Chapter 4).
What You Need
Conversion log generated by the FactoryTalk View ME Import Wizard for the
imported application.
Follow These Steps
Follow these steps to review how PanelBuilder32 objects and alarms map to
FactoryTalk View ME software. This information helps you correct
application errors that are listed in the conversion log.
Reviewing Object Mapping
Page 62
Reviewing Data Type
Mapping
Page 62
Reviewing Mapping of
Communication Networks
Page 63

Allen-Bradley PanelView Plus 7 Specifications

General

Operating System	Windows CE 6.0
Memory	512 MB RAM
Mounting	Panel mount
Display Type	Color TFT LCD
Processor	ARM Cortex-A8
Storage	512 MB Flash
Communication Ports	Ethernet, USB, Serial
Input Voltage	24V DC
Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Rating	NEMA 4X
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Relative Humidity	5% to 95% non-condensing
Certifications	CE, UL, cUL
Display Sizes	4.3", 7", 10", 15", 19"
Touchscreen	Resistive or Projected Capacitive (depending on model)
