Allen-Bradley PanelView Plus 7 Migration Guide

70 Rockwell Automation Publication 2711P-AP006C-EN-P - November 2018
Chapter 7 Qualify the Runtime Application
Follow These Steps
Follow these steps to configure diagnostics, validate, test run, configure global
memory connections, download, and run your converted application on a
PanelView Plus 7 terminal.
Review Diagnostic Lists
On your development computer, FactoryTalk View ME software features a
diagnostic list at the bottom of the application window. You can configure
FactoryTalk diagnostics to display information, warnings, and errors during
application development and runtime.
When you test run your application, the diagnostic list displays messages and
errors that are logged by the application. Use this list to identify the graphic
objects or features that generated the messages or errors. Correct these errors
during the validation process.
Review Diagnostic Lists
Configure the Runtime
Diagnostic Display
Page 70
Page 71
Review Error States for
Graphic Objects
Page 73
Configure Communication
Page 74
Test Run the Application
Page 78
Page 76
Test Run Graphic Displays

Allen-Bradley PanelView Plus 7 Specifications

General

Operating System	Windows CE 6.0
Memory	512 MB RAM
Mounting	Panel mount
Display Type	Color TFT LCD
Processor	ARM Cortex-A8
Storage	512 MB Flash
Communication Ports	Ethernet, USB, Serial
Input Voltage	24V DC
Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Rating	NEMA 4X
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Relative Humidity	5% to 95% non-condensing
Certifications	CE, UL, cUL
Display Sizes	4.3", 7", 10", 15", 19"
Touchscreen	Resistive or Projected Capacitive (depending on model)
