Allen-Bradley PanelView Plus 7 Migration Guide

Rockwell Automation Publication 2711P-AP006C-EN-P - November 2018 45
Select a Terminal Replacement Chapter 2
Function Key Comparisons
The table provides a comparison of function keys between the PanelView
Standard and PanelView Plus 7 terminals.
Table 2 - PanelView Plus Replacement Terminals
PanelView Standard
Terminal
PanelView Plus 7 Replacement Terminal Adapter Kit
Required
Adapter Kit
Cat. No.
PanelView Standard 300 or
300 Micro
None
(1)
——
PanelView 550 or 600 touch PanelView Plus 400 keypad or keypad/touch
PanelView Plus 600 touch
No —
PanelView 550 keypad
PanelView 550 keypad/
touch
PanelView Plus 600 keypad or keypad/touch No —
PanelView Plus 400 keypad or keypad/touch
PanelView Plus 600 touch
Yes 2711P-RAK4
PanelView 600 keypad
PanelView 600 keypad/
touch
PanelView Plus 600 keypad or keypad/touch Yes 2711P-RAK6
PanelView Plus 700 keypad or keypad/touch No —
PanelView 900 keypad PanelView Plus 700 keypad or keypad/touch Yes 2711P-RAK7
PanelView Plus 1000 keypad or keypad/touch No —
PanelView 900 touch PanelView Plus 700 touch Yes 2711P-RAT7
PanelView Plus 1000 touch No —
PanelView 1000 keypad PanelView Plus 1000 keypad or keypad/touch Yes 2711P-RAK10
PanelView Plus 1250 keypad or keypad/touch No —
PanelView 1000 touch PanelView Plus 1000 touch Yes 2711P-RAT10
PanelView Plus 1250 touch No —
PanelView 1400 keypad PanelView Plus 1250 keypad or keypad/touch Yes 2711P-RAK12S
PanelView Plus 1500 keypad or keypad/touch No —
PanelView 1400 touch PanelView Plus 1250 touch Yes 2711P-RAT12S
PanelView Plus 1500 touch No —
(1) You can replace the PanelView Standard 300 or 300 Micro with a PanelView Plus 400 keypad terminal by increasing the size of
the current panel cutout.
Table 3 - Function Key Comparisons Between Terminal Platforms
PanelView Standard
Keypad or Keypad/Touch
PanelView
Standard
Function Keys
PanelView
Plus 7
Function Keys
PanelView Plus 7 Terminal
Keypad or Keypad/Touch
300M keypad F1…F4
300 keypad F1…F8 F1…F8 400 keypad or keypad/touch
550 keypad or keypad/touch F1…F10 F1…F10 600 keypad or keypad/touch
600 keypad or keypad/touch F1…F10 F1…F10,
K1…K12
700 keypad or keypad/touch
900 keypad F1…F16 F1…F16,
K1…K16
1000 keypad or keypad/touch
1000 keypad F1…F16 F1…F20,
K1…K20
1250 keypad or keypad/touch
1400 keypad F1…F16,
F17…F21
F1…F20,
K1…K20
1500 keypad

Allen-Bradley PanelView Plus 7 Specifications

General

Operating System	Windows CE 6.0
Memory	512 MB RAM
Mounting	Panel mount
Display Type	Color TFT LCD
Processor	ARM Cortex-A8
Storage	512 MB Flash
Communication Ports	Ethernet, USB, Serial
Input Voltage	24V DC
Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Rating	NEMA 4X
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Relative Humidity	5% to 95% non-condensing
Certifications	CE, UL, cUL
Display Sizes	4.3", 7", 10", 15", 19"
Touchscreen	Resistive or Projected Capacitive (depending on model)
