Allen-Bradley PanelView Plus 7 Migration Guide

Rockwell Automation Publication 2711P-AP006C-EN-P - November 2018 43
Select a Terminal Replacement Chapter 2
Accessories
Some accessories and accessory catalog numbers are new or have changed for
PanelView Plus 7 Standard and PanelView Plus 7 Performance terminals. See
the accessories section in the respective user manuals that are listed in
Additional Resources
on page 10 for a list of accessories and catalog numbers
for the terminals.
Legacy Communication Support
PanelView Plus 7 terminals use only Ethernet communication. If you need
support for non-Ethernet communication protocols, go to the following
Encompass™ Partner websites:
• http://www.anybus.com/products/prodindex.shtml
• http://www.prosoft-technology.com/Products/Gateways
PanelView Enhanced 1000e, 1200e, 1400e Terminals Secondary Replacement Options
PanelView Standard Terminals PanelView Plus 7 Terminals – Secondary Replacement Options
Panel Cutout
Dimensions
Panel Cutout
Dimensions
Model Cat. No.
Height mm (in.) Width mm (in.)
Display
Resolution
Comm. Cat. No.
Height mm (in.) Width mm (in.)
Display
Resolution
Comm.
Adapter
Kit Cat.
No.
Notes
1000e
2711E-K10C15
282
(11.11)
423
(16.64)
640 x 480
ControlNet
2711P-B15C22A9P
290
(11.42)
418
(16.46)
1024 x 768
Dual
Ethernet
ports
N/A PanelView Plus 7
Performance 15 in.
terminal benefits:
•Higher resolution
•DLR
Communication =
Ethernet.
Operator input = Keypad
and touch.
Power input = AC.
Conformal coat = No.
2711E-K10C6 Remote I/O
2711E-T10C15
370
(14.58)
ControlNet
No secondary option available.
2711E-T10C6 Remote I/O
1200e
2711E-K12C6
355
(13.97)
483
(19.0)
800 x 600
Remote I/O 2711P-B15C22A9P
290
(11.42)
418
(16.46)
1024 x 768
Dual
Ethernet
ports
N/A
2711E-T12C4
342
(13.50)
351
(13.8)
RS-232
No secondary option available.
1400e
2711E-K14C15
355
(13.97)
483
(19.0)
800 x 600
ControlNet
2711P-T15C21D8S
290
(11.42)
353
(13.90)
1024 x 768
One
Ethernet
port
N/A
PanelView Plus 7 Standard
15 in. terminal benefits:
Higher resolution
Application limits:
• Max. screen count: 25
• Max. alarm messages:
200
•Max. number of
controllers: 1
Communication =
Ethernet (dual Ethernet
ports are available).
Operator input = only
touch.
Power input = only DC.
Conformal coat = No.
2711E-K14C6 Remote I/O
2711E-T14C15
442
(17.38)
ControlNet
2711E-T14C6 Remote I/O

Allen-Bradley PanelView Plus 7 Specifications

General

Operating System	Windows CE 6.0
Memory	512 MB RAM
Mounting	Panel mount
Display Type	Color TFT LCD
Processor	ARM Cortex-A8
Storage	512 MB Flash
Communication Ports	Ethernet, USB, Serial
Input Voltage	24V DC
Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Rating	NEMA 4X
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Relative Humidity	5% to 95% non-condensing
Certifications	CE, UL, cUL
Display Sizes	4.3", 7", 10", 15", 19"
Touchscreen	Resistive or Projected Capacitive (depending on model)
