Allen-Bradley PanelView Plus 7 Migration Guide

Rockwell Automation Publication 2711P-AP006C-EN-P - November 2018 25
Select a Terminal Replacement Chapter 2
600
2711-B6C15
192
(7.55)
290
(11.40)
320 x 234
ControlNet
2711P-B7C22A9P
142
(5.59)
237
(9.33)
640 x 480
Dual
Ethernet
ports
2711P-
RAAK7
PanelView Plus 7 Performance
6.5 in. terminal benefits:
•Higher resolution
•DLR
Communication = Ethernet.
Operator input = keypad and
touch.
Power input = AC or DC.
Conformal coat = No.
Adapter kit is necessary for
drop-in replacement.
2711-B6C15L1 2711P-B7C22D9P
2711-B6C2
DH-485
2711P-B7C22A9P
2711-B6C2L1 2711P-B7C22D9P
2711-B6C3 2711P-B7C22A9P
2711-B6C3L1 2711P-B7C22D9P
2711-B6C5
RS-232
(DH-485)
2711P-B7C22A9P
2711-B6C5L1 2711P-B7C22D9P
2711-B6C9 2711P-B7C22A9P
2711-B6C9L1 2711P-B7C22D9P
2711-B6C8
DH+
2711P-B7C22A9P
2711-B6C8L1 2711P-B7C22D9P
2711-B6C20
EtherNet/IP
2711P-B7C22A9P
2711-B6C20L1 2711P-B7C22D9P
2711-T6C1L1
152
(6.0)
185
(7.28)
320 x 234
Remote I/O
2711P-T6C21D8S
123
(4.84)
156
(6.14)
640 x 480
One
Ethernet
port
N/A
PanelView Plus 7 Standard 6 in.
terminal benefits:
Higher resolution
Application limits:
• Max. screen count: 25
• Max. alarm messages: 200
• Max. number of controllers: 1
Communication = Ethernet
(dual Ethernet ports are
available).
Operator input = only touch.
Power input = only DC.
Conformal coat = No.
2711-T6C10L1
DeviceNet
2711-T6C14L1
2711-T6C12L1 RS-232
2711-T6C16L1
RS-232
(DF1)
2711-T6C15L1 ControlNet
2711-T6C2L1
DH-485
2711-T6C3L1
2711-T6C5L1
RS-232
(DH-485)
2711-T6C9L1
2711-T6C8L1 DH+
2711-T6C20L1 EtherNet/IP
PanelView Standard 600 Terminals Primary Replacement Options (continued)
PanelView Standard Terminals PanelView Plus 7 Terminals – Primary Replacement Options
Panel Cutout
Dimensions
Panel Cutout
Dimensions
Model Cat. No.
Height mm (in.) Width mm (in.)
Display
Resolution
Comm. Cat. No.
Height mm (in.) Width mm (in.)
Display
Resolution
Comm.
Adapter
Kit Cat.
No.
Notes

Allen-Bradley PanelView Plus 7 Specifications

General

Operating System	Windows CE 6.0
Memory	512 MB RAM
Mounting	Panel mount
Display Type	Color TFT LCD
Processor	ARM Cortex-A8
Storage	512 MB Flash
Communication Ports	Ethernet, USB, Serial
Input Voltage	24V DC
Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Rating	NEMA 4X
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Relative Humidity	5% to 95% non-condensing
Certifications	CE, UL, cUL
Display Sizes	4.3", 7", 10", 15", 19"
Touchscreen	Resistive or Projected Capacitive (depending on model)
