Allen-Bradley PanelView Plus 7 Migration Guide

4 Rockwell Automation Publication 2711P-AP006C-EN-P - November 2018
Where to Start
Follow this path to migrate your PanelView Standard terminal and application
to the PanelView Plus 7 terminal platform.
Chapter 1
Things to Know Before
You Migrate
Chapter 2
Select a Terminal
Replacement
Chapter 3
Import Your Application
Chapter 4
Review the Application
Conversion Log
Chapter 5
Review Object Mapping
Chapter 9
Optimize Runtime
Performance
Appendix A
Advanced Object
Editing
Chapter 6
Review Unsupported
Features
Chapter 7
Qualify the Runtime
Application
Before you update the migrated
application, review the conversion
log details and the remaining
chapters. If you determine that the
conversion operation would not be
feasible, you can use the conversion
services that are provided by
Rockwell Automation. For more
information, see Conversion
Services, publication GMSC10-
PP009.
Chapter 8
Create the Runtime
Application

Allen-Bradley PanelView Plus 7 Specifications

General

Operating System	Windows CE 6.0
Memory	512 MB RAM
Mounting	Panel mount
Display Type	Color TFT LCD
Processor	ARM Cortex-A8
Storage	512 MB Flash
Communication Ports	Ethernet, USB, Serial
Input Voltage	24V DC
Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Rating	NEMA 4X
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Relative Humidity	5% to 95% non-condensing
Certifications	CE, UL, cUL
Display Sizes	4.3", 7", 10", 15", 19"
Touchscreen	Resistive or Projected Capacitive (depending on model)
