Coupling and uncoupling the machine
ZA-X BAG0235.4
WARNING
Risk of contusions, cutting, catching, drawing in and knocks
when the machine unexpectedly releases from the tractor!
• Use the intended equipment to connect the tractor and the ma-
chine in the proper way.
• When coupling the machine to the tractor's three-point hydraulic
system, ensure that the attachment categories of the tractor and
the machine are the same.
Upgrade the category II upper link and lower link pins on the
machine to category III using reducing sleeves if your tractor is
equipped with category III three-point hydraulics.
•
Only use the upper and lower link pins provided to couple up the
machine.
• Check the
upper and lower link pins for visible defects whenever
the machine is coupled. Replace the upper and lower link pins in
the event of clearly visible wear.
• Secure the upper link pin and lower link pin in the connecting
points of the three-point attachment frame against unintentional
detachment using a lynch pin.
WARNING
Risk of energy supply failure between the tractor and the ma-
chine through damaged power lines!
During coupling, check the course of the power lines. The power lines
• must give slightly without tension, bending or rubbing on all
movements of the connected machine.
• may not scour other parts.
1. Fasten the ball sleeves over the upper link pins and fasten the
lower link pins in the pivot points of the three-point attachment
frame.
→ Do not pin upper and lower links of category II using category I
pins!
2. Secure the upper link pin and the lower link pin against uninten-
tional detachment, using one lynch pin for each.
WARNING
If the lower link pins have one-sided bearings or are welded in,
use ball sleeves with socket and integrated lynch pin.
Risk of accident when disconnecting the machine from the trac-
tor!
