Ametek 3050-OLV

PN 305200901, Rev YT
cm
inches
To
Dryer
In
Sample
Exhaust
Out
From
Dryer
RS-232 Out
RS-485 In RS-485 Out
Power
Signal Connections
1.27
(.50)
3.61
(1.42)
2.22
(.88)
7.62
(3.00)
3.81
(1.50)
7.62
(3.00)
3.81
(1.50)
15.04
(5.92)
12
3
12
3
45678910 1112
TB-1
TB-2
50 PSI MAX
RS-232
Out
Exhaust
50 PSI Max
In
Sample
Dryer
To
Dryer
From
Figure 2-2.
3050-OLV Analyzer rear view.
Installation and Start-Up | 2-7
