2-6 | Model 900 ADA / Model 930 Sulfur Pit Analyzers
Cable Entry Ports, Type 200 Disconnect Enclosure
M25 x 1.5, 6H cable entries are provided for Power (1 entry) and Signals
(2 entries). See the Model 9xx-Series Analyzer Type 200 Disconnect
Enclosure Details drawing in Appendix A for cable entry locations. In all
cases, all unused cable entry ports must be plugged with a certified Ex d
plug.
Approvals and Certications
The Model 900 ADA and Model 930 Analyzers are certified for indoor use
only, Installation Category II (local level transients, less than those found
at power distribution level), and Pollution Degree 2 (normally noncon-
ductive environmental pollution occurs with occasional condensation).
Complies with all relevant European Directives.
Approvals and certifications include:
NEC/CEC: Class I, Zone 2 (Div 2), Groups C&D, NFPA 496 Z-Purge
ATEX/IECEx: Purged Analyzer:
DEKRA Certificate No.: KEMA 02ATEX2341 X;
II 2 G Ex db eb ia pxb IIB T3 Gb
IECEx Certificate No.: IECEx DEK 13.0054X;
Ex db eb ia pxb IIB T3 Gb
Heater Plate:
DEKRA Certificate No.: KEMA 02ATEX2255 X;
II 2 G Ex db IIB T3 Gb
IECEx Certificate No.: IECEx DEK 11.0073X;
Ex db IIB T3 Gb
Disconnect Enclosure Type 200:
DEKRA Certificate No.: KEMA 01ATEX2219 X;
II 2 G Ex db IIB T6 Gb
IECEx Certificate No.: IECEx DEK 12.0077X;
Ex db IIB T6 Gb
GOST: 1ExpydIIBT3
Complies with all relevant European Directives,
GOST Pattern Approval
EMC: Electromagnetic Compatibility Directive:
2014/30/EU,
with EN61326 Industrial
LVD: Low Voltage Directive: 2014/35/EU, with EN61010-1
RoHS: Restriction of Hazardous Substances Directive:
2011/65/EU (RoHS 2)
