Installation and Start-Up | 3-35
Start-Up Diagnostic Checklist
This checklist describes problems that may be encountered while power-
ing up the analyzer and preparing it for normal operation. If the analyzer
experiences problems during power-up, review this checklist and perform
the corresponding corrective action to fix any problems.
Problem Encountered
“Reset in Progress” message does not appear on the User Interface immedi-
ately after applying AC power, or after attempting a manual system reset.
Corrective Action
Simultaneously press • and Ent. If this message still does not appear, take
necessary precautions and check the AC wiring to ensure it is properly
connected.
Problem Encountered
If is displayed on the User Interface, alarms are active. The character will
typically be displayed upon start-up due to low temperatures in the tempera-
ture zones.
Corrective Action
View the HStatus (HS) and MStatus (MS) screens to determine which alarms
are active. See “Host Controller/Microcontroller Board Alarm Conditions and
Corrective Action” in Chapter 5.
Problem Encountered
One or both source lamps are not firing.
Corrective Action
Take appropriate safety precautions and check for proper wiring connections.
If the wiring is okay, check the lamp socket connections. Review “Replacing
the Source Lamps” in Chapter 5 to make adjustments to the lamps. Perform
an Auto-Setup if necessary to ensure the lamps are operating at peak
efficiency.
(HS) RUNF5 41..8
(MS) RUNF5 51..7
