Installation and Start-Up | 3-13
Installing the Sample System
Final “As-Built” drawings of the analyzer sample system components
are included in the analyzer Documentation Package.
Installing the ASR900 Sample Probe
For information on installing the ASR900 Sample Probe, refer to the
ASR900 Sample Probe Installation and Maintenance Guide. Also, refer to
Final “As-Built” drawings which include important information to follow
during installation.
Installing the Sample and Vent Lines
The Sample and Vent Lines can be supplied by AMETEK or the customer.
This section assumes these lines are supplied by AMETEK.
Do not lift or support the Sample or Vent Lines by their tubing fit-
tings. Doing so can pull the fitting off the sample transport tube. A
wire mesh cable support must be installed on the line before lifting it
and when a line is to be suspended vertically. The Sample and Vent
Lines are custom-built for each installation; they cannot be cut to
length on-site.
To avoid damaging the Sample or Vent Lines, use two wrenches to
ensure that the fitting body does not turn on the Teflon tube.
To install the Sample and Vent Lines:
1. If an explosion-proof power-disconnect switch has already been
installed for the Sample and Vent Lines, open it to ensure there is no
power being supplied to these temperature zone circuits.
Keep the power-disconnect switch open until the entire system has
been installed, the leak check has been completed, and the analyzer is
ready for normal operation.
