Ametek 930 User Manual

Specications | 2-15
ATEX- and IECEx-certified Model 900/Model 930 Purged Analyzers are
marked with one of the labels shown below (depends on application).
Systems with 30 psia Pressure Transducer (Maximum 63 kPag Sample Gas
Pressure)
Systems with 100 psia Pressure Transducer (Maximum 350 kPag Sample
Gas Pressure)
See manual before opening.
Minimum purging flow rate:
Minimum purging duration:
Internal free volume:
Minimum overpressure:
Maximum overpressure:
Maximum leakage rate:
40 Nl/min
15 minutes
124 litres
50 Pa
1000 Pa
10 Nl/min
WARNING - PRESSURIZED ENCLOSURE
Do not open while a flammable atmosphere is present.
Western Research Series 9XX Analyzer
Certificate No: KEMA 02ATEX2341 X
Year. _______
Serial No. ___________________
Ex db eb ia pxb IIB T3 Gb (T amb. -20°C to +50°C)
108-132V = 6.2A MAX
Power Dissipation < 100W
216-264V = 3.1A MAX
47-63Hz
Minimum Supply Pressure:
Maximum Supply Pressure:
60 psig / 4 barg
115 psig / 8 barg
AMETEK CANADA LP
IECEx DEK 13.0054X
Maximum Sample Gas Pressure: 63 kPag
II 2 G
0344
See manual before opening.
Minimum purging flow rate:
Minimum purging duration:
Internal free volume:
Minimum overpressure:
Maximum overpressure:
Maximum leakage rate:
40 Nl/min
15 minutes
124 litres
50 Pa
1000 Pa
10 Nl/min
WARNING - PRESSURIZED ENCLOSURE
Do not open while a flammable atmosphere is present.
Western Research Series 9XX Analyzer
Certificate No: KEMA 02ATEX2341 X
Year. _______
Serial No. ___________________
Ex db eb ia pxb IIB T3 Gb (T amb. -20°C to +50°C)
108-132V = 6.2A MAX
Power Dissipation < 100W
216-264V = 3.1A MAX
47-63Hz
Minimum Supply Pressure:
Maximum Supply Pressure:
60 psig / 4 barg
115 psig / 8 barg
IECEx DEK 13.0054X
Maximum Sample Gas Pressure: 350 kPag
II 2 G
0344
AMETEK CANADA LP
