3-6 | Model 900 ADA / Model 930 Sulfur Pit Analyzers
To install the analyzer:
Install the analyzer at an accessible location as close as possible to the sam-
ple extraction point to minimize sample response time and, if the Sample
Line must be heated, minimize the heating requirements.
For shelter installations, refer to Final “As-Built” shelter drawings in the
analyzer Documentation Package.
Figure 3-1 illustrates a typical Zone 1 analyzer layout. While the
backpan mounting hole locations and dimensions generally do not
change, the plumbing and external wiring will likely change for each
installation.
For other analyzer configurations, refer to Final “As-Built” drawings
in the analyzer Documentation Package.
NOTE
