User Manual – Rev BE AMETEK Programmable Power

MX Series 106

selection followed by pressing the ‘ENTER’ key. Alternatively, the MENU key

may be pressed to move to the MENU 2 screen.

The present cursor position is always shown with an inverse bar. The cursor is

located on the ‘MORE’ selection in Figure 4-7. Pressing ENTER would cause

MENU 2 to be displayed.

The cursor position can be moved by using the UP and DOWN keys located in

the DECIMAL keypad.

Figure 4-7: Main Menu 1 Screen

Table of Contents9
