User Manual – Rev BE AMETEK Programmable Power
MX Series 53
The input power cables, and protective circuit breaker used must be specified to
handle the input current and input voltage of the power source and must
conform to local electrical codes. Consult a qualified electrician prior to
installation. Table 3-1 shows the size of the cables that may be used per MX
cabinet. Note that wires must be sized to accommodate the worst-case
maximum current that may occur under low line conditions. Local electrical
codes may also require different wire types and sizes. These ratings should also
be used when selecting a circuit breaker or equivalent disconnect device.
Cable lengths must not exceed twenty-five (25) feet. For lengths greater than
25 feet, calculate the voltage drop from the following equation:


= 2  ×  × 
Where: D = Length of cable
R= Resistance per foot of cable
I = Current in Amps
E
drop
= voltage drop
Table 3-1: Suggested Input Wiring Sizes for each MX30 / MX45 Cabinet *
*
Using high temperature rated wire. Always consult the National Electrical Code and/or local code
regulations for proper rating and size of wire cabling prior to installation.
Fo r Ea c h MX
Ca b i n e t
Nominal Line
Vo l t a g e
Load Current @
lo w l in e
Wire Gauge
( US)
Circular Mils
( Kc m i l s )
Me t r i c ( m m 2 )
MX3 0
600V
40 ARMS
10 AWG
10.4
5.3
480 V
50 ARMS
10 AWG
10.4
5.3
400 V
60 ARMS
8 AWG
16.5
8.4
380V
64 ARMS
8 AWG
16.5
8.4
230 V
105 ARMS
4 AWG
41.7
21.2
208 V
116 ARMS
4 AWG
41.4
21.2
MX4 5
600V
60 ARMS
8 AWG
16.5
8.4
480 V
Error!
Reference
source not
found.
6 AWG
26.2
13.3
400 V
Error!
Reference
source not
found.
4 AWG
41.7
21.2
380V
95 ARMS
4 AWG
41.7
21.2
230 V
Error!
Reference
source not
found.
2 AWG
66.4
33.6
208 V
Error!
Reference
source not
found.
1 AWG
83.7
42.4
