User Manual – Rev BE AMETEK Programmable Power

MX Series 79

3.7.6 USB Interface

A standard USB Series B device connector is located on the rear panel for

remote-control. A standard USB cable between the AC Source and a PC or USB

Hub may be used.

NOTE: Use of the USB port to control more than one power source from

a single PC is not recommended, as communication may not be

reliable. Use GPIB interface for multiple power source control.

Figure 3-16: USB Connector Pin Orientation.

Na me

Description

1 VBUS + 5 VDC

2 D- Data -

3 D+ Data +

4 GND Gr o u n d

Table 3-10: USB Connector Pin-out.
