MX Series 236
7.4 Advanced Troubleshooting.
WARNING: Do not connect 400-480V into the 208-240V unit, the result
could be a severely damaged unit.
CAUTION: VOLTAGES UP TO 480 VAC AND 450 VDC ARE PRESENT IN
CERTAIN SECTIONS OF THIS POWER SOURCE.
WARNING: THIS EQUIPMENT GENERATES POTENTIALLY LETHAL
VOLTAGES. DEATH ON CONTACT MAY RESULT IF PERSONNEL
FAIL TO OBSERVE SAFETY PRECAUTIONS. DO NOT TOUCH
ELECTRONIC CIRCUITS WHEN POWER IS APPLIED
7.4.1 Switch Off Unit
Switch off the unit at the circuit breaker on the front panel as well as removing
the input power from the unit.
WARNING: Wait 10 minutes for all internal capacitors to discharge.
7.4.2 Removing Covers
Remove the screws securing the front cover and remove it.
Remove the screws securing the top cover and remove it.
7.4.3 Initial Inspection
Make a visual inspection of the unit and ensure all the connectors are properly
mated and there are no loose wires.
7.4.4 Fuse Check
Using an ohmmeter, check input fuses F1, F2 and F3 for continuity.
