User Manual – Rev BE AMETEK Programmable Power
MX Series 256
The above tests can be selected by scrolling to the highlighted selection using
the up and down key and the ENTER key to start the selected test. For some of
these tests, numeric data entry may be required to define the test number or
the modulation rate.
VOLT FREQ MIN
Vo l t a g e
1 100 104 104 104
3 101.5 105.5 105.5 105.5
Frequency
380 390 360 360
Table 9-1: Normal Voltage and Frequency Minimum
Vo l t a g e
1 122 122 122 122
3 120.5 120.5 120.5 120.5
Frequency
420 410 650 800
Table 9-2: Normal Voltage and Frequency Maximum
This test will set the voltage and frequency to levels defined by Table 9-1. The
test will last for 30 minutes. The test will be repeated for the Group 2 and 3
using the Voltage setting from Table 9-2 and the frequency from Table 9-1. The
← key (backspace) will terminate the test at any time.
VOLT FREQ MAX
This test will set the voltage and frequency to levels defined by Table 9-2. The
test will last for 30 minutes. The test will be repeated for the EURO standard
using the Voltage setting from Table 9-1 and the frequency from Table 9-2.
The CLR Key in local operation will terminate the test at any time. Group
execute trigger will terminate the test remotely. The unselected phases will
remain at 115 volts. The ← key (backspace) will terminate the test at any
time.
VOLT UNBALANCE
Voltage offset 6 6 6 9
Frequency 400 400 360/ 650 360/800
Table 9-3: Normal Voltage Unbalance
This test will change the output voltage for each phase from 115 volts to 115V
+ offset. Refer to Table 9-3 for the offset value and the Frequency. The test will
last 30 minutes. The test will be repeated for a second Frequency if applicable.
The test can be terminated at any time.
The ← key will terminate the test at any time.
WAVEFORM DISTORTION
