Ametek MX45-3Pi - Table 6-1: Calibration Load Values

User Manual – Rev BE AMETEK Programmable Power
MX Series 210
measurement calibration coefficients are used on both voltage ranges (if
available).
Suggested load values are shown for either voltage range in case the MX
configuration used only has a single voltage range. (MX45-N-150 or MX45-N-
300).
PARAMETER
POWER SYSTEM
Mo d e l --->
Lo we s t Ra n g e
MX3 0 -1 / MX3 0 -3Pi
1 phase mode
MX3 0 -3 /
MX3 0 -3Pi 3
phase mode
MX6 0 -3(Pi)
150 VAC / 200 VDC
AC Current Full Scale 0.48 Ω, 30 kW 1.5 Ω, 10 kW 0.75 Ω, 20 kW
DC Current Full Scale 0.9 Ω, 15 kW 2.67 Ω, 5.kW 1.34 Ω, 10.kW
DC Current Zero Scale 80 Ω, 350 W 80 Ω, 350 W 80 Ω, 350 W
300 VAC / 400 VDC
AC Current Full Scale 1.9 Ω, 30 kW 5.7 Ω, 10 kW 2.8 Ω, 10 kW
DC Current Full Scale 2.9 Ω, 15 kW 8.7 Ω, 5.kW 4.3 Ω, 5.kW
DC Current Zero Scale 80 Ω, 350 W 80 Ω, 350 W 80 Ω, 350 W
PARAMETER
POWER SYSTEM
Mo d e l --->
Lo we s t Ra n g e
MX4 5 -1 / MX4 5 -
3Pi 1 phase mode
MX4 5 -3 / MX4 5 -3Pi
3 phase mode
MX9 0 -3(Pi)
MX135-3(Pi)
150 VAC / 200 VDC
AC Current Full Scale 0.33 Ω, 44 kW 1.0 Ω, 14.4 kW 0.5 Ω, 30KW 0.33 Ω, 44 kW
DC Current Full Scale 0.9 Ω, 28.5 kW 2.67 Ω, 9.6.kW 1.33 Ω, 7.5KW 0.9 Ω, 28.5 kW
DC Current Zero Scale 80 Ω, 350 W 80 Ω, 350 W 80 Ω, 350 W 80 Ω, 350 W
300 VAC / 400 VDC
AC Current Full Scale 1.2 Ω, 44 kW 4.0 Ω, 14.4 kW 2.0 Ω, 30KW 1.2 Ω, 44 kW
DC Current Full Scale 3.6 Ω, 28.5 kW 10.67 Ω, 9.6.kW 5.3 Ω, 7.5KW 3.6 Ω, 28.5 kW
DC Current Zero Scale 80 Ω, 350 W 80 Ω, 350 W 80 Ω, 350 W 80 Ω, 350 W
Table 6-1: Calibration Load Values
6.3.1 Measurement Cal - AC
To calibrate AC measurements, set the power source to the AC mode. Select the
MEASUREMENT CAL entry from the MENU 3 screen. Refer to section 4.2.13 for
relevant LCD screen.
NOTE: For the following calibration steps put the external Digital
Multimeter into the AC mode.
