User Manual – Rev BE AMETEK Programmable Power
MX Series 151
MIL704 Indicates the presence of the MIL/STD-704 Revision D
and E test option. If this option is installed, this field
will show ON. If this option is not installed, this field will
show N/A (not available).
CONFIGURATION SETUP 2
IEC 4-11 Indicates the presence of the IEC 1000-4-11 test
option. If this option is installed, this field will show ON.
If this option is not installed, this field will show N/A
(not available).
IEC 4-13 Indicates the presence of the IEC 1000-4-13 test
option. If this option is installed, this field will show ON.
If this option is not installed, this field will show N/A
(not available).
CLOCK/LOCK Indicates the presence of the -LKS clock and lock
auxiliary option. For units without -LKS, this field is set
to N/A. For units with the -LKS option installed, this
field is set to ON. Note that master unit (with -LKM)
also has this field set to N/A.
WH METER Indicates the presence of the Watt Hour Meter option.
SYSTEM Shown here on Series I models only. See
CONFIGURATION SETUP 3 screen below.
CONFIGURATION SETUP 3 (Series II models only)
MS704 Indicates the presence of the MIL/STD-704 Revision A
through F test option. If this option is installed, this
field will show ON. If this option is not installed, this
field will show N/A (not available). This field is available
on Series II MX systems only.
ABD Indicates the presence of the ABD0100.1.8 test option.
If this option is installed, this field will show ON. If this
option is not installed, this field will show N/A (not
available). This field is available on Series II MX
systems only.
LF Indicates the presence of the Low Frequency limit
option. If this option is set, the maximum frequency
that can be programmed is 500 Hz. This field is
available on Series II MX systems only.
